Custom Tumor Ablation Needle by ZorayPT

ZorayPT’s Tumor Ablation Needle is a precision-engineered solution designed for safe and effective tumor ablation procedures, ensuring reliability and accuracy in minimally invasive oncology treatments. As a leading one-stop OEM/ODM manufacturer, with all in-house plastic molding, metal processing, and cleanroom assembly, we deliver superior quality custom Tumor Ablation Needles tailored for advanced tumor treatment interventions. The needle features a length of 50mm-200mm (customizable), outer diameter of 18G-22G (0.7mm-1.2mm, customizable), and an active tip length of 5mm-20mm (customizable), compatible with RF, microwave, or cryotherapy systems for versatile use. Produced in our ISO 13485-certified Class 100,000 cleanroom, the Tumor Ablation Needle is made of high-grade medical stainless steel (SUS304/SUS316L), or titanium for electrode, customizable, with PTFE or Parylene insulation (customizable) to ensure safety during energy delivery. It includes a sharp beveled or blunt tip (customizable), radiopaque marker, scale marking for precise positioning, depth limiter for controlled insertion, and sterile packaging (EO sterilization, double-layer), all single-use with customizable design options to meet specific needs. This needle is ideal for tumor ablation procedures, providing precision in applications such as liver cancer, lung cancer, and kidney cancer ablation. ZorayPT can tailor Tumor Ablation Needles based on client-provided samples, drawings, or specifications, offering advanced manufacturing processes such as Multi-faceted grinding, Marking, Bending, Drilling, Head forming, Taper reduction Flaring, Threading, Chamfering, Flanging, Grooving, Flattening, Diameter changing, Developing, Polishing coating, Syringe base, Base mold, and Die casting mold. Need a tailored design? We can develop custom solutions to meet your exact requirements, with handle options including short, long, or T-shaped designs. Ideal for oncology and minimally invasive procedures, ZorayPT provides OEM/ODM solutions with faster lead times and cost-efficiency. Trust ZorayPT for your Tumor Ablation Needle needs in cutting-edge medical interventions.

Key Features

• Material: High-grade medical stainless steel (SUS304/SUS316L), or titanium for electrode, customizable.
• Dimensions: Length (50mm-200mm), Outer Diameter (18G-22G, 0.7mm-1.2mm), Active Tip (5mm-20mm), customizable.
• Design Features: Sharp beveled or blunt tip (customizable), radiopaque marker, scale marking, depth limiter, sterile packaging (EO sterilization, double-layer), single-use, customizable.
• Ablation Type: Compatible with RF, microwave, or cryotherapy systems.
• Insulation: PTFE or Parylene insulation, customizable.
• Connector Type: Luer Lock, Ablation System Connector, or customized interface.
• All In-House: One-stop production guarantees superior quality.

Applications

ZorayPT Tumor Ablation Needles are ideal for:

• Liver Cancer Ablation: Effective for targeted liver tumor treatment.
• Lung Cancer Ablation: Precise ablation for lung tumors.
• Kidney Cancer Ablation: Reliable for minimally invasive kidney tumor interventions.
  With ISO 13485 standards and faster lead times, we provide cost-efficient solutions. Contact us to customize your Tumor Ablation Needle.

Why Choose ZorayPT?

• One-Stop Manufacturing: All in-house plastic molding, metal processing, and cleanroom assembly.
• ISO 13485 Certified: Meets global standards in a Class 100,000 cleanroom.
• Superior Quality: Precision tools for medical excellence.
• Faster Lead Times: Automated production for quick delivery.
• Cost-Efficiency: Integrated manufacturing reduces costs.
• Advanced Customization: ZorayPT can customize needles based on client-provided samples, drawings, or specifications, offering processes like Multi-faceted grinding, Marking, Bending, Drilling, Head forming, Taper reduction Flaring, Threading, Chamfering, Flanging, Grooving, Flattening, Diameter changing, Developing, Polishing coating, Syringe base, Base mold, and Die casting mold.
  Enhance your tumor ablation procedures with ZorayPT’s solutions. Contact us today!

Tumor Ablation Needle Specifications
